Model	SL001-1-50	SL001-1-60	SL001-2-100	SL001-2-120	SL001-3-150	SL001-3-180	SL001-4-200	SL001-4-240	SL001-5-300
POWER	50W	60W	100W	120W	150W	180W	200W	240W	300W
DRIVER	Meanwell	Meanwell	Meanwell	Meanwell	Meanwell	Meanwell	Meanwell	Meanwell	Meanwell
LED CHIP	Bridgelux	Bridgelux	Bridgelux	Bridgelux	Bridgelux	Bridgelux	Bridgelux	Bridgelux	Bridgelux
COB	1*50W	1*60W	2*50W	2*60W	3*50W	3*60W	4*50W	4*60W	5*60W
CASING MATERIAL	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy
ANGLE REGULATION	±15°	±15°	±15°	±15°	±15°	±15°	±15°	±15°	±15°
VOLTAGE	85-265VAC	85-265VAC	85-265VAC	85-265VAC	85-265VAC	85-265VAC	85-265VAC	85-265VAC	85-265VAC
FREQUENCY	50/60 Hz	50/60 Hz	50/60 Hz	50/60 Hz	50/60 Hz	50/60 Hz	50/60 Hz	50/60 Hz	50/60 Hz
POWER FACTOR	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95	>0.95
LIGHT LUMINOUS(LM),  EPISTAR OR BRIDGELUX	4750lm/5250lm	5700lm/6300lm	9500lm/10500lm	11400lm/12600lm	14250lm/15750lm	17100lm/18900lm	19000lm/21000lm	22800lm/25200lm	28500lm/31500lm
CORRELATED COLOR TEMP.(CCT)	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K	2700~6500K
COLOR RENDERING INDEX (CRI)	75	75	75	75	75	75	75	75	75
BEAN ANGLE	135*60°	135*60°	135*60°	135*60°	135*60°	135*60°	135*60°	135*60°	135*60°
PROTECTION GRADE	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67
LIFE SPAN	50000H	50000H	50000H	50000H	50000H	50000H	50000H	50000H	50000H
WARRANTY	5 years	5 years	5 years	5 years	5 years	5 years	5 years	5 years	5 years
AMBIENT HUMIDITY	≤95%	≤95%	≤95%	≤95%	≤95%	≤95%	≤95%	≤95%	≤95%
AMBIENT  TEMP.	-40°C~55°C	-40°C~55°C	-40°C~55°C	-40°C~55°C	-40°C~55°C	-40°C~55°C	-40°C~55°C	-40°C~55°C	-40°C~55°C
PCS/CARTON	1	1	1	1	1	1	1	1	1
PRODUCT SIZE (mm)	442*340*115mm	442*340*115mm	564*340*115mm	564*340*115mm	686*340*115mm	686*340*115mm	808*340*115mm	808*340*115mm	930*340*115mm
PACKING SIZE (mm)	500*392*185mm	500*392*185mm	630*392*185mm	630*392*185mm	760*392*185mm	760*392*185mm	875*392*185mm	875*392*185mm	985*392*185mm
N.W.(kg)	6	6	8	8	10	10	12	12	14
G.W.(kg)	7	7	9	9	11	11	13	13	15
REMARK	1.For the LED Street light, still need Pole, PV Panel , PV mounting,Solar Charge Controller, Solar Battery and Battery Box. pls inquire while need.
	2.CCT: Warm white(WW) 2700-3500K;Natural white(NW)4000-4500K;Cold white(CW) 6000-6500K
