Temperature Coefficients of Isc (%)℃ -0.04 %/ºC
Allowable Hail Load 23m/s ,7.53g
Temperature Coefficients of Voc (%)℃ -0.33 %/ºC
Junction Box Type Pass the TUV Certificate
Temperature Coefficients of Pmax (%)℃ 0.047
Front Cover Low-iron tempered glass
Nominal Operating Cell Temperature(NOCT) 45±2°C
Caple & Connector Type Pass the TUV Certificate
Operating Module Temperature - 40°C to+85°C
Backing (Brand Type) TPT
Power Tolerance ±3%
Standard Test Conditions AM1.5 1000W/ 25 +/-2℃
Surface Maximum Load Capacity 2400Pa
Frame Anodized aluminum alloy
Warranty 10year Warranty on material;output 90% after 10 years, output 80% after 25 years. |  |
|
Model |
Max power
at STC |
Cell
Size |
Cell
Array |
Module
Efficiency |
Max Power
Current |
Max Power
Voltage |
Short
Circuit
Current |
Open
Circuit
Voltage |
Cable with
Connector |
Max system
Voltage |
Rated
Fuse |
Product
Size |
Product
Weight |
|
|
Pmax,W |
mm |
PCS |
academic
value% |
IMP,Amp |
VMP,Vdc |
ISC,Amp |
VOC,Vdc |
Meter |
VDC |
Amp |
mm |
KG |
|
GYM10-36 |
10 |
62.5*31.25 |
4*9 |
16 |
0.574 |
17.421 |
0.854 |
21.021 |
NO |
NO |
600 |
NO |
360*290*17 |
1.4 |
|
GYM20-36 |
20 |
78*39 |
4*9 |
18 |
1.1 |
18.2 |
1.3 |
22.3 |
NO |
NO |
600 |
NO |
420*290*17 |
2.1 |
|
GYM30-36 |
30 |
156*31.2 |
3*12 |
18.2 |
1.639 |
18.3 |
1.94 |
21.9 |
NO |
NO |
600 |
NO |
450*510*25 |
3.5 |
|
GYM40-36 |
40 |
156*39 |
4*9 |
17.6 |
2.185 |
18.3 |
2.485 |
21.9 |
NO |
NO |
600 |
NO |
420*670*25 |
4 |
|
GYM50-36A |
50 |
125*62.5 |
4*9 |
18.6 |
2.718 |
18.4 |
3.018 |
22 |
NO |
NO |
600 |
NO |
630*540*30 |
4.4 |
|
GYM50-36B |
50 |
156*52 |
4*9 |
18.2 |
2.74 |
18.25 |
2.95 |
22.7 |
2.5sqmm,0.5m |
mc4 |
750 |
2*8A |
540*670*30 |
4.5 |
|
GYM75-36 |
75 |
156*78 |
4*9 |
18.2 |
4.1 |
18.25 |
4.37 |
21.85 |
2.5sqmm,0.5m |
mc4 |
750 |
2*8A |
780*670*30 |
6.4 |
|
GYM80-36A |
80 |
156*78 |
4*9 |
17.6 |
4.395 |
18.202 |
4.925 |
21.802 |
2.5sqmm,0.5m |
mc4 |
750 |
2*8A |
780*670*30 |
6.7 |
|
GYM85-36 |
85 |
156*78 |
4*9 |
18 |
4.395 |
18.202 |
4.925 |
21.802 |
2.5sqmm,0.5m |
mc4 |
750 |
2*8A |
780*670*30 |
6 |
|
GYM100-36 |
100 |
125*125 |
4*9 |
18.6 |
5.319 |
18.8 |
5.96 |
22.8 |
4sqmm,0.9m |
mc4 |
750 |
2*10A |
1200*540*35 |
8.5 |
|
GYM100-36 |
100 |
156*104 |
4*9 |
17.6 |
5.45 |
18.348 |
6.318 |
22 |
4sqmm,0.9m |
mc4 |
750 |
2*10A |
1010*670*35/30 |
8.5 |
|
GYM120-36 |
120 |
156*130 |
4*9 |
17.6 |
6.722 |
17.85 |
7.26 |
21.42 |
4sqmm,0.9m |
mc4 |
1000 |
2*10A |
1240*670*35 |
9.5 |
|
GYM130-36 |
130 |
19 |
7.065 |
18.4 |
7.603 |
22 |
4sqmm,0.9m |
mc4 |
1000 |
2*10A |
|
GYM140-36 |
140 |
156*156 |
4*9 |
17 |
7.865 |
17.8 |
8.395 |
21.5 |
4sqmm,0.9m |
mc4 |
1000 |
2*10A |
1480*670*35 |
12 |
|
GYM145-36 |
145 |
17.6 |
7.9 |
18.354 |
8.43 |
21.954 |
4sqmm,0.9m |
mc4 |
1000 |
2*12A |
|
GYM150-36 |
150 |
18.2 |
8.08 |
18.564 |
8.61 |
22.164 |
4sqmm,0.9m |
mc4 |
1000 |
2*15A |
|
GYM155-36 |
155 |
18.8 |
8.2 |
18.902 |
8.73 |
22.502 |
4sqmm,0.9m |
mc4 |
1000 |
2*15A |
|
GYM160-36 |
160 |
19.4
|
8.32 |
19.23 |
8.85 |
22.83 |
4sqmm,0.9m |
mc4 |
1000 |
2*15A |
|
GYM200-236 |
200 |
125*125 |
6*12 |
18.6 |
10.753 |
18.6 |
12.9 |
22.3 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
1580*808*35 |
15.5 |
|
GYM200-72 |
200 |
18.6 |
5.264 |
38 |
5.96 |
45.6 |
4sqmm,0.9m |
mc4 |
1000 |
3*10A |
1580*808*35 |
15.5 |
|
GYM200-48 |
200 |
156*156 |
6*8 |
18.2 |
8.02 |
24.938 |
8.96 |
30.958 |
4sqmm,0.9m |
mc4 |
1000 |
3*10A |
1320*992*35 |
15.8 |
|
GYM210-48 |
210 |
19 |
8.2 |
25.61 |
9.14 |
31.63 |
4sqmm,0.9m |
mc4 |
1000 |
3*10A |
|
GYM215-48 |
215 |
19.5 |
8.25 |
26.06 |
9.19 |
32.08 |
4sqmm,0.9m |
mc4 |
1000 |
3*10A |
|
GYM235-54 |
235 |
156*156 |
6*9 |
19 |
8.22 |
28.589 |
8.758 |
35.964 |
4sqmm,0.9m |
mc4 |
1000 |
3*10A |
1480*992*35 |
17.8 |
|
GYM240-54 |
240 |
19.4 |
8.28 |
28.985 |
8.818 |
36.36 |
4sqmm,0.9m |
mc4 |
1000 |
3*10A |
|
GYM245-60 |
245 |
156*156 |
6*10 |
17.8 |
8.033 |
30.5 |
8.581 |
38.875 |
4sqmm,0.9m |
mc4 |
1000 |
6*10A |
1640*992*35/40/45 |
19.5 |
|
GYM250-60 |
250 |
18.2 |
8.084 |
30.931 |
8.632 |
39.306 |
4sqmm,0.9m |
mc4 |
1000 |
6*10A |
|
GYM255-60 |
255 |
18.6 |
8.12 |
31.42 |
8.668 |
39.795 |
4sqmm,0.9m |
mc4 |
1000 |
6*10A |
|
GYM260-60 |
260 |
18.8 |
8.2 |
31.7 |
8.748 |
40.075 |
4sqmm,0.9m |
mc4 |
1000 |
6*10A |
|
GYM265-60 |
265 |
19.2 |
8.26 |
32.082 |
8.808 |
40.043 |
4sqmm,0.9m |
mc4 |
1000 |
6*10A |
|
GYM270-60 |
270 |
19.6 |
8.321 |
32.45 |
8.868 |
40.41 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM275-60 |
275 |
20 |
8.381 |
32.812 |
8.893 |
40.772 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM280-60 |
280 |
20.4 |
8.484 |
33.003 |
8.996 |
40.963 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM285-60 |
285 |
20.7 |
8.6 |
33.139 |
9.112 |
41.099 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM290-60 |
290 |
21 |
8.72 |
33.256 |
9.232 |
41.216 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM290-72 |
290 |
156*156 |
6*12 |
17.6 |
8.023 |
36.147 |
8.571 |
44.492 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
1950*992*45/50 |
22 |
|
GYM295-72 |
295 |
17.8 |
8.054 |
36.63 |
8.602 |
44.975 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM300-72 |
300 |
18.2 |
8.085 |
37.11 |
8.623 |
45.485 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM305-72 |
305 |
18.6 |
8.11 |
37.62 |
8.658 |
45.665 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM310-72 |
310 |
18.8 |
8.21 |
37.758 |
8.758 |
45.9 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM315-72 |
315 |
19 |
8.289 |
38 |
8.837 |
46.142 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM320-72 |
320 |
19.4 |
8.376 |
38.204 |
8.924 |
46.346 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM325-72 |
325 |
19.6 |
8.463 |
38.402 |
9.011 |
46.526 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM330-72 |
330 |
20 |
8.558 |
38.56 |
9.106 |
46.684 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM335-72 |
335 |
20.4 |
8.678 |
38.6 |
9.226 |
46.724 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
GYM340-72 |
340 |
20.7 |
8.785 |
38.702 |
9.35 |
46.826 |
4sqmm,0.9m |
mc4 |
1000 |
6*12A |
|
