Model |
TSG(B)10KVA |
TSG(B)15KVA |
TSG(B)20KVA |
TSG(B)30KVA |
TSG(B)40KVA |
TSG(B)50KVA |
TSG(B)60KVA |
|
Output |
Rated Output Power |
8KW |
12KW |
16KW |
24KW |
32KW |
40KW |
48KW |
|
Rated Output Current |
12.1A |
18.2A |
24.3A |
36.4A |
48.6A |
60.7A |
72.8A |
|
Phase number |
three phase, 3P+N+PE, 380/400/415VAC |
|
waveform |
Pure sine wave |
|
AC current crest factor |
3:01 |
|
Overload capacity |
105%~110%, 10mins; 110%~125%, 1min; >125%, 10s |
|
Voltage THD |
THDU<3%, linear load; THDU<5%, nonlinear load |
|
Isolation |
Low frequency transformer |
|
MPPT Controller & PV input |
MPP voltage range (Vdc) |
250V~450V |
420V~650V |
|
Max. input voltage (Vdc) |
460 |
660 |
|
Recommended rated voltage (Vdc) |
Around 330V |
Around 480V |
|
Output voltage range (VDC) |
192~264 |
310~420 |
|
Max. controller module number |
2 |
2 |
2 |
4 |
4 |
5 |
5 |
|
Standard PV Input Module |
1 |
1 |
2 |
3 |
3 |
4 |
4 |
|
MPPT output current (A) |
50 |
40 |
|
MPPT efficiency |
99.50% |
|
Module dimension(D*W*H mm) |
415*356*84.5 |
335*436*84.5 |
|
Module Weight (KG) |
11 |
|
Single Module Max PV Input Power |
11KW |
16KW |
|
Single Module Max PV Input Current |
45A |
37A |
|
AC Input and power charger (OPTION) |
AC input voltage range (Vac) |
three phase, 3P+N+PE, 380/400/415VAC |
|
AC input frequence range (Hz) |
50/60±5% |
|
Rated charge Voltage |
220VDC |
348VDC |
|
Max. AC charger power |
7.5KW |
7.5KW |
15KW |
22.5KW |
30KW |
37.5KW |
45KW |
|
Max. AC charger current (A) |
31.25 |
31.25 |
62.5 |
93.75 |
76.9 |
96.15 |
115.38 |
|
Battery type |
220VDC Lead-acid or Li battery |
384VDC Lead-acid or Li battery |
|
Display |
LED |
Run,Power/ Alarm, Fault |
|
LCD |
AC input AC, PV Vdc, MPPT Vdc Amp, Power Charger Vdc Amp, Output AC Amp and Load %, Solar generating capacity and graph, Fault code and event recorder, parameter setup , Inverter/ Controller ON OF Control, clock and Timer |
|
Communication |
RS485, dry contact |
|
Protections |
Input over/under voltage, output over/under voltage, Battery Over charge and low voltage, overload, short circuit, over temperature, reverse polarity |
|
Ingress protection rating |
IP20 |
|
System efficiency |
up to 95% |
|
Night power consume |
less than 100W |
|
Operating temperature range (°C) |
–20~50 (>50°C derating) |
|
Relative humidity in operation |
0~95% (non-condensing) |
|
Max. operating altitude (m) |
6000 (>3000m derating) |
|
product size (D*W*H mm) |
560*460*1040 |
600*550*1450 |
600*600*1600 |
|
Product Weight (KG) |
180 |
210 |
230 |
320 |
400 |
450 |
450 |
|
REMARK |
TSG- No AC Bypass and Charger, TSG-B with AC Bypass and Charger |
