ITEM |
MODEL |
SMD600 |
SMD650 |
SMD800 |
SMD1000 |
SMD1250 |
SMD1500 |
|
Capacity |
600VA/360W |
650VA/390W |
800VA/480W |
1KVA/600W |
1.2KVA/750W |
1.5KVA/900W |
|
Input |
Input Voltage |
75-150 or 145-290+-5VAC |
|
Input Frequency |
50/60HZ+-5% (AUTO Sensing) |
|
Output |
Wave Form |
Modified Sine Wave |
|
Output Voltage |
120/220/230/240VAC;50-127V,100-255V |
|
Transfer Time |
4~6ms normal ,Max8Ms |
|
Output Frequency |
50.0/60Hz±1.0Hz (Battery Mode),follow Main while AC Mode |
|
Battery And Charger |
Battery protection |
FUSE |
|
DC Voltage |
12VDC |
24VDC |
|
Internal Battery |
1*7AH |
1*7AH |
1*9AH |
2*7AH |
2*7AH |
2*9AH |
|
Backup time |
3-20Minutes(1PC+15 inch CRT) |
30-60Minutes(1PC+15 inch CRT) |
40-80Minutes(1PC+15 inch CRT) |
|
Protection |
Over charge and over discharge,short Circuit,Overload |
|
Display |
LED display for AC/ DC mode and Fault. LCD is option |
|
Alarm |
Alarm while DC mode/ Battery low / Overload /Battery replacement. |
|
Enviromental Characteristics |
Ambient Temp. |
0 to 40 degree celsius |
|
Relative Humidity |
0% to 90% |
|
Storage Temp. |
-15 to 40 degree celsius |
|
Noise Level |
40dB(Max) |
|
Product Size |
305*85*140 |
305*85*140 |
305*85*140 |
324*100*153 |
324*100*153 |
324*100*153 |
|
Packing Size (MM) |
380*278*443 |
380*278*443 |
380*278*443 |
415*410*298 |
415*410*298 |
415*410*298 |
|
PCS/CTN |
4 |
4 |
4 |
2 |
2 |
2 |
|
Gross Weight /CTN (KG) |
22.8/CTN |
23/CTN |
26/CTN |
22.8/CTN |
22.8/CTN |
25.6/CTN |
