ITEM

MODEL

SMT400

SMT500

SMT600

SMT650

SMT800

 Capacity

 Output power

400VA/240W

500VA/300W

600VA/360W

650VA/390W

800VA/480W

 Input

 Voltage range

75-150 or 140-290+-5VAC

 Power Factor

0.98 ,R Load

 Frequency range

40-70HZ,  self-adapt

 Output

 Voltage

220V or 110V ± 10% ( Line Mode ), 220V or 110V ± 5%  (battery mode)

 Frequency (battery  mode)

50 or 60 ± 1Hz  self-adapt

 Transfer time

<10Ms

 Waveform

Modified sine wave (battery mode)

 Overload

110% < Load ≤ 120%, Shutdown after 5 mins, Load>120% shutfown immediately

 Battery

 Type

Sealed lead acid, maintenance free

 DC voltage

12VDC

 Battery number

1*12V/4.2AH

1*12V/4.2AH

1*12V/7AH

1*12V/7AH

1*12V/9AH

 Low Cut Point

10V ± 0.5V

 Standby time

Full load >3min,half load >8min

 Recharge

After fully discharged, charge 8 hours to 90% capacity

 Protecting

 overload

Fuse & current limited when overloaded

 Battery low voltage

Automatically lock out the machine so as to protect the Battery from over discharging

 Short circuit

Fuse & current limited

 Restart

Auto restart when AC recovery.

 Alarm

 Battery back-up

Sounding every 4 seconds

 Battery low

Sounding every 1 second,

 Battery Replace

Sounding every 2 seconds

 Overload

continously

 Indicator

 LED

LED indicator for line on, battery back-up, charging , Fault

 product Size

 L*W*H(mm)

265*95*140

265*95*140

350*105*155

350*105*155

350*105*155

 Carton size

 L*W*H(mm)

590*315*235mm/4PCS

590*315*235mm/4PCS

385*315*235/2PCS

385*315*235/2PCS

385*315*335/2PCS

 Package weight

 Kg

18/4PCS

18/4PCS

11/2PCS

11/2PCS

13.4/2PCS
