ITEM

MDOE

SMD500P

SMD500PA

SMD600P

SMD650P

SMD1000P

Capacity

500VA/300W

500VA/300W

600VA/360W

650VA/390W

1000VA/500W

Input

Input voltage range

90-132Vac / 175-265Vac

85-150Vac / 145-290Vac

Frequency range

45-65Hz

Output

Output voltage

110/120Vac or 220/230/240Vac

Output voltage range

90-132Vac / 175-265Vac

102-132Vac / 200-255Vac

Output frequency

60±0.5Hz or 50±0.5Hz(Batt. Mode)

Output wave form

Modified Sine Wave ( bat Mode )

Transfer time

Typical 2-6ms,10ms max

Battery

DC Voltage

12VDC

12VDC

12VDC

12VDC

12VDC

internal Battery

1*4.5AH

1*4.5AH

1*7AH

1*7AH

1*9AH

Recharge time

4-6 hours recover to 90% capacity

Protection

Full protection

Low voltage, overload, short circuit, battery low Voltage protection

Display

LED

LED display for AC/ DC mode and Fault. LCD is option

LCD ( Option)

IP /OP VAC HZ , Load % , bat Charge discharge state, bat %  ,Working mode,

Alarm

Alarm while DC mode/ Battery low / Overload /Battery replacement.

Enviromental Characteristics

Ambient Temp.

0 to 40 degree celsius

Relative Humidity

0% to 90%

Storage Temp.

-15 to 40 degree celsius

Noise Level

40dB(Max)

Management

LCD or LEC,RJ45/11 & USB

Optional

Product Size mm

255*98*140

300*95*140

Packing Size (MM)

310*298*400mm

310*298*400mm

358*298*400mm

358*298*400mm

358*298*400mm

PCS/CTN

4

4

4

4

2

Gross Weight /CTN (KG)

15.2/CTN

15.6/CTN

19.2/CTN

19.6/CTN

21.4/CTN
